LUMATEK 1000w Pro 400v Dimmable & Controllable Ballast

BALLAST USAGE

This is our most powerful intelligent ballast, the 1000W which integrates the proven and reliable Lumatek technology and with an addition of Control capability. The LUMATEK Pro 1000W 400v Controllable has been developed to connect to 240V power supply and light 600/750/1000W 400V HPS grow lamps.

400V grow lighting is now standard in professional horticulture because of the extra PAR/PPF (grow light) produced with greater efficiency and lower energy costs. Improved PAR ensures a constant and uniform plant growth.

BALLAST TECHNOLOGY

Lumatek use the latest electronic components to improve performance & efficiency to reduce the cost of high-end professional equipment for the end user.

Lumatek Pro ballasts are tested and compatible with 400V DE HPS lamps from all the leading manufacturers including Phillips. Comparison testing has demonstrated up to 10% more PAR/PPF than standard horticultural lamps with improved PAR maintenance levels.

The total cable length between the Pro 1000W 400V Ballast and reflector should not exceed 5 meters.

KEY SPECIFICATIONS

Product Code: LUMBC006
Size L x W x H(mm): 318 x 166 x 96
Weight (Kg): 4.9
Case: Graduated Fin Aluminium
Dimming (W): 600W - 750W - 1000W – Super Lumens (115%)
Mains Supply Voltage: 240V 50Hz
Input Input Current Max (A): 5.1
Input Power (W): 1200
Output Power (W): 1150
Operating Frequency (KHz): 125
Power Factor: 0.99
THD(%): <10
Efficiency(%): 96
Mains Voltage Range(V): 175 – 275
Lamp: 600W, 750W, 1000W HPS

KEY FEATURES

Developed to meet professional standards & the main requirements of growers:
• Additional PAR/PPF – up to 10% more grow light
• More light = more yield/revenue
• Improved PAR Light Output maintenance
• Highest System Efficiency
• High reliability
• Low energy costs
• Affordable price – little more than standard 240V equipment
• Connect to 240V power supply and light 400V Double Ended horticultural grow lights
• Full circuit protection; open/short, over temperature, over/low voltage, end of lamp life/rectification
• EMI suppression certified
