ATS200W PRO producing a PPF of 508 µmol/s , achieving a high efficacy of 2.5 µmol/J. 90% light output at 60,000 h, verified!
EFFICACY & PPF
Precision-engineered for smaller grow areas, the Lumatek ATS 200W PRO delivers big results in a compact frame. This lightweight fixture outputs a PPF of 508 µmol/s with a fixture efficacy of 2.5 µmol/J, making it an ideal solution for spaces measuring 0.8 by 0.8 meters. Whether you´re managing a single cultivar or running a multi-strain micro grow, it provides consistent, high-quality light for strong plant development from seed to flower.
The upgraded diode layout now spans the entire length of each LED bar, creating a broader and more uniform light footprint across the canopy. Thanks to Lumatek’s refined engineering and advances in LED tech, the ATS PRO delivers high output performance with passive convection cooling. Its fanless build eliminates moving parts, resulting in silent operation, extended fixture life, and reliable durability in demanding grow environments.
DIODE TECHNOLOGY
Lumatek ATS PRO series are designed with a precise blend of white, deep red, and far red diodes to deliver a full-spectrum output optimised for plant absorption. This carefully balanced spectrum supports vigorous vegetative growth and rich flowering while maintaining high intensity, uniformity, and stable performance across the entire grow area.
Earlier generations of LED fixtures relied heavily on royal blue and deep red diodes to target chlorophyll absorption peaks. While effective in part, they lacked broader wavelengths essential for overall plant health, offered limited canopy penetration, and made visual inspections difficult under their narrow, harsh light. Lumatek’s diode strategy addresses these limitations, providing a more comprehensive and grower-friendly solution for serious cultivation.
PRODUCT CONFIGURATION
The redesigned array of the ATS PRO series delivers a consistent, high-uniformity light spread at close range, ensuring excellent canopy penetration without generating hotspots or excessive heat. This precision makes it ideal for compact cultivation setups, vertical systems, or low-ceiling environments.
Equipped with an innovative heat sink and cooled through passive natural convection, the fixture operates silently with no need for fans or moving parts. This fanless design not only reduces noise but also extends the fixture’s lifespan, making it a durable and low-maintenance solution for serious growers.
For propagation, early veg, or light-sensitive cultivars, the ATS200W PRO is fully dimmable—allowing you to adjust light intensity without compromising efficiency. Its low-powered, high-efficiency LED bar configuration helps keep diode temperatures down, improving long-term light stability and output consistency. This smart thermal design ensures reliable results across every stage of the grow while helping you manage power consumption with precision.
KEY SPECIFICATIONS
PRODUCT CODE: LUMLED200P
EFFICACY: 2.5 µmol/J
PPF: 508 µmol/s
INPUT VOLTAGE: 220-240V, 50-60Hz
INPUT POWER at 100%: 205 W (±2%) @230 V AC
FOOTPRINT: 0.8 x 0.8 m
WATERPROOF: IP65
L90: 90% output at 60,000 h
LIGHT DISTRIBUTION: 120°
THERMAL MANAGEMENT: Passive Cooling
DIMMABLE: OFF-25%-50%-75%-100% with 0-10V Light Dimmer (Included)
EXTERNAL CONTROL: With Lumatek Controller or Universal Controller 0-10V, 1% steps
WEIGHT: 4 Kg
DIMENSIONS: 525 x 525 x 72 mm
SPECTRUM: Full Spectrum +
WARRANTY: 3 Years
CERTIFICATIONS: CE, EMC, LVD, TISI, RCM, L90
BTU: 703 BTUs/h (Max)
KEY FEATURES
- L90: 90% output at 60,000 h
- Efficacy of 2.5 µmol/J
- PPF output of 508 µmol/s
- High quality LUMATEK driver
- Top bin LEDs
- Balanced full spectrum
- Clear Glue protection cover technology on LED bars
- Improved light spread and uniformity
- External control with Lumatek Controllers or Universal Controllers 0-10V
- Compact design ideal for up to 0.8 x 0.8 m grow area
- Fully Dimmable
- User friendly Plug & Play Assembling
- 3 Year Warranty
ITEMS INCLUDED:
- 1 x ATS200W Pro LED Fixture with Driver
- 1 x Power Cable 230V
- 1 x 0-10V Light Dimmer + Velcro
- 2 x Metal Cable Hangers
- 1 x Product Manual
CONTROL SYSTEMS
This Lumatek LED fixture is fully compatible with external control systems, including the Lumatek Digital Panel Plus 2.0. Manage light timing, automated dimming in one per cent increments, temperature safety features, and dynamic Sunrise and Sunset Modes. Control up to 100 fixtures from a single controller and fine-tune your lighting environment with professional precision.
Universal Control Systems Compatibility
Whether you´re using Lumatek´s controller or another system with a 0-10V output signal, you´re covered. Even if your setup includes a controller with an RJ port interface, our LED fixtures remain compatible by using a signal converter that adapts the RJ port to 0-10V control. That means flexibility across platforms without needing to overhaul your existing gear. Designed for scalability and ease of integration, Lumatek empowers growers to take full command of their lighting setups, from tents to large-scale operations.
